Exosomes in serum‑free cultures of THP‑1 macrophages infected with <em>Mycobacterium tuberculosis</em>

Biadglegne,Fantahun; Rademacher,Phil; De Sulbaran,Yarúa Gabriela Jaimes; König,Brigitte; Rodloff,Arne C.; Zedler,Ulrike; Dorhoi,Anca; Sack,Ulrich

doi:10.3892/mmr.2021.12455

Exosomes in serum‑free cultures of THP‑1 macrophages infected with Mycobacterium tuberculosis

Authors:
- Fantahun Biadglegne
- Phil Rademacher
- Yarúa Gabriela Jaimes De Sulbaran
- Brigitte König
- Arne C. Rodloff
- Ulrike Zedler
- Anca Dorhoi
- Ulrich Sack
View Affiliations

Affiliations: Department of Medical Laboratory Science, College of Medicine and Health Sciences, Bahir Dar University, 79 Bahir Dar, Ethiopia, Institute of Clinical Immunology, Medical Faculty, University of Leipzig, D‑04103 Leipzig, Germany, Institute of Medical Microbiology and Epidemiology of Infectious Diseases, University of Leipzig, D‑04103 Leipzig, Germany, Institute of Immunology, Friedrich Loeffler Institut, D‑17493 Greifswald Insel Riems, Germany
Published online on: September 22, 2021 https://doi.org/10.3892/mmr.2021.12455
Article Number: 815
Copyright: © Biadglegne et al. This is an open access article distributed under the terms of Creative Commons Attribution License.

Metrics: Total Views: 0 (Spandidos Publications: | PMC Statistics: )

Metrics: Total PDF Downloads: 0 (Spandidos Publications: | PMC Statistics: )

Cited By (CrossRef): 0 citations Loading Articles...

Abstract

It has been shown from the isolation and characterization of exosomes from cell culture media supplemented with fetal bovine serum that both their quality and purity are affected. The high abundance of serum proteins, including bovine cell derived exosomes, is also a potential source of contaminants, which may result in appreciable yields of impure exosomes, thereby leading to artifacts. Isolation and characterization of exosomes from cells maintained under serum‑free conditions should therefore ensure the high quality necessary for medical applications. To meet this end, the present study aimed to characterize exosomes released from THP‑1 macrophages cultured in serum‑free, ultra‑centrifuged medium upon infection with the human pathogen Mycobacterium tuberculosis (Mtb). Macrophages differentiated from the human cell line THP‑1 were infected at a multiplicity of infection (MOI) of 5. Macrophages were cultivated in CellGenix^® GMP DC serum‑free ultra‑centrifuged medium for 4, 24 and 48 h at 37˚C in a humidified atmosphere with 5% CO₂. Total exosome isolation reagent was used to extract the exosomes from the cell culture supernatants of naïve and Mtb‑infected THP‑1 macrophages. The size and purity of the exosomes isolated were subsequently assessed by various methods, including nanoparticle tracking analysis, flow cytometry, MACSPlex exosome analysis, and western blotting. The serum‑free, ultra‑centrifuged medium was found to support the proliferation of the THP‑1 cells successfully. The nanoparticle tracking analysis data revealed that the majority of the isolated particles were within the size range of exosomes (i.e., 30‑150 nM). The MACSPlex exosome analysis confirmed the expression of the exosomal markers, CD9, CD63 and CD81. Furthermore, western blot analysis of the isolated exosomes indicated the presence of CD9, CD63, CD81 and lysosomal associated membrane protein‑1 (LAMP‑1), and also confirmed the absence of Mtb proteins. Taken together, these data provide evidence that serum‑free, ultra‑centrifuged CellGenix^® GMP DC medium is suitable for application in exosome research, and may significantly advance such studies. Therefore, the use of serum‑free medium for exosome isolation purposes could offer considerable advantages, and constitute a significant improvement in the growing field of extracellular vesicle research. The use of more sensitive methods represents an advance that will enable researchers to rule out the presence of Mtb pathogenic proteins in exosomes isolated from infected serum‑free cell cultures.

View Figures

View References

1	World Health Organization (WHO), . Global Tuberculosis Report 2018. WHO; Geneva: pp. 2312018
2	World Health Organization (WHO), . WHO Guidelines on Tuberculosis Infection Prevention and Control: 2019 Update. WHO; Geneva: pp. 622019
3	van der Pol E, Böing AN, Harrison P, Sturk A and Nieuwland R: Classification, functions, and clinical relevance of extracellular vesicles. Pharmacol Rev. 64:676–705. 2012. View Article : Google Scholar : PubMed/NCBI
4	Lee S-S, Won J-H, Lim GJ, Han J, Lee JY, Cho K-O and Bae Y-K: A novel population of extracellular vesicles smaller than exosomes promotes cell proliferation. Cell Commun Signal. 17:952019. View Article : Google Scholar : PubMed/NCBI
5	Patel GK, Khan MA, Zubair H, Srivastava SK, Khushman M, Singh S and Singh AP: Comparative analysis of exosome isolation methods using culture supernatant for optimum yield, purity and downstream applications. Sci Rep. 9:53352019. View Article : Google Scholar : PubMed/NCBI
6	Diaz G, Wolfe LM, Kruh-Garcia NA and Dobos KM: Changes in the Membrane-Associated Proteins of Exosomes Released from Human Macrophages after Mycobacterium tuberculosis Infection. Sci Rep. 6:379752016. View Article : Google Scholar : PubMed/NCBI
7	Kruh-Garcia NA, Wolfe LM, Chaisson LH, Worodria WO, Nahid P, Schorey JS, Davis JL and Dobos KM: Detection of Mycobacterium tuberculosis peptides in the exosomes of patients with active and latent M. tuberculosis infection using MRM-MS. PLoS One. 9:e1038112014. View Article : Google Scholar : PubMed/NCBI
8	Zhang Y, Liu Y, Liu H and Tang WH: Exosomes: Biogenesis, biologic function and clinical potential. Cell Biosci. 9:192019. View Article : Google Scholar : PubMed/NCBI
9	Lobb RJ, Becker M, Wen SW, Wong CSF, Wiegmans AP, Leimgruber A and Möller A: Optimized exosome isolation protocol for cell culture supernatant and human plasma. J Extracell Vesicles. 4:270312015. View Article : Google Scholar : PubMed/NCBI
10	Zeringer E, Li M, Barta T, Schageman J, Pedersen KW, Neurauter A, Magdaleno S, Setterquist R and Vlassov AV: Methods for the extraction and RNA profiling of exosomes. World J Methodol. 3:11–18. 2013. View Article : Google Scholar : PubMed/NCBI
11	Rosas LE, Elgamal OA, Mo X, Phelps MA, Schmittgen TD and Papenfuss TL: In vitro immunotoxicity assessment of culture-derived extracellular vesicles in human monocytes. J Immunotoxicol. 13:652–665. 2016. View Article : Google Scholar : PubMed/NCBI
12	Tauro BJ, Greening DW, Mathias RA, Ji H, Mathivanan S, Scott AM and Simpson RJ: Comparison of ultracentrifugation, density gradient separation, and immunoaffinity capture methods for isolating human colon cancer cell line LIM1863-derived exosomes. Methods. 56:293–304. 2012. View Article : Google Scholar : PubMed/NCBI
13	Abramowicz A, Marczak L, Wojakowska A, Zapotoczny S, Whiteside TL, Widlak P and Pietrowska M: Harmonization of exosome isolation from culture supernatants for optimized proteomics analysis. PLoS One. 13:e02054962018. View Article : Google Scholar : PubMed/NCBI
14	Singhal N, Sharma P, Kumar M, Joshi B and Bisht D: Analysis of intracellular expressed proteins of Mycobacterium tuberculosis clinical isolates. Proteome Sci. 10:142012. View Article : Google Scholar : PubMed/NCBI
15	Théry C, Amigorena S, Raposo G and Clayton A: Isolation and characterization of exosomes from cell culture supernatants and biological fluids. Curr Protoc Cell Biol Chapter. 3:Unit 3.22. 2006.doi.org/10.1002/0471143030.cb0322s30. PubMed/NCBI
16	Hu X, Liao S, Bai H, Wu L, Wang M, Wu Q, Zhou J, Jiao L, Chen X, Zhou Y, et al: Integrating exosomal microRNAs and electronic health data improved tuberculosis diagnosis. EBioMedicine. 40:564–573. 2019. View Article : Google Scholar : PubMed/NCBI
17	Biadglegne F, König B, Rodloff AC, Dorhoi A and Sack U: Composition and Clinical Significance of Exosomes in Tuberculosis: A Systematic Literature Review. J Clin Med. 10:E1452021. View Article : Google Scholar
18	Tang Y-T, Huang Y-Y, Zheng L, Qin S-H, Xu X-P, An T-X, Xu Y, Wu Y-S, Hu X-M, Ping B-H, et al: Comparison of isolation methods of exosomes and exosomal RNA from cell culture medium and serum. Int J Mol Med. 40:834–844. 2017. View Article : Google Scholar : PubMed/NCBI
19	Arteaga-Blanco LA, Mojoli A, Monteiro RQ, Sandim V, Menna-Barreto RFS, Pereira-Dutra FS, Bozza PT, Resende RO and Bou-Habib DC: Characterization and internalization of small extracellular vesicles released by human primary macrophages derived from circulating monocytes. PLoS One. 15:e02377952020. View Article : Google Scholar : PubMed/NCBI
20	Atha DH and Ingham KC: Mechanism of precipitation of proteins by polyethylene glycols. Analysis in terms of excluded volume. J Biol Chem. 256:12108–12117. 1981. View Article : Google Scholar : PubMed/NCBI
21	Wiklander OPB, Bostancioglu RB, Welsh JA, Zickler AM, Murke F, Corso G, Felldin U, Hagey DW, Evertsson B, Liang X-M, et al: Systematic Methodological Evaluation of a Multiplex Bead-Based Flow Cytometry Assay for Detection of Extracellular Vesicle Surface Signatures. Front Immunol. 9:13262018. View Article : Google Scholar : PubMed/NCBI
22	Helwa I, Cai J, Drewry MD, Zimmerman A, Dinkins MB, Khaled ML, Seremwe M, Dismuke WM, Bieberich E, Stamer WD, et al: A Comparative Study of Serum Exosome Isolation Using Differential Ultracentrifugation and Three Commercial Reagents. PLoS One. 12:e01706282017. View Article : Google Scholar : PubMed/NCBI
23	Gercel-Taylor C, Atay S, Tullis RH, Kesimer M and Taylor DD: Nanoparticle analysis of circulating cell-derived vesicles in ovarian cancer patients. Anal Biochem. 428:44–53. 2012. View Article : Google Scholar : PubMed/NCBI
24	Caradec J, Kharmate G, Hosseini-Beheshti E, Adomat H, Gleave M and Guns E: Reproducibility and efficiency of serum-derived exosome extraction methods. Clin Biochem. 47:1286–1292. 2014. View Article : Google Scholar : PubMed/NCBI
25	Keller BO, Sui J, Young AB and Whittal RM: Interferences and contaminants encountered in modern mass spectrometry. Anal Chim Acta. 627:71–81. 2008. View Article : Google Scholar : PubMed/NCBI
26	Smith VL, Cheng Y, Bryant BR and Schorey JS: Exosomes function in antigen presentation during an in vivo Mycobacterium tuberculosis infection. Sci Rep. 7:435782017. View Article : Google Scholar : PubMed/NCBI
27	Koliha N, Wiencek Y, Heider U, Jüngst C, Kladt N, Krauthäuser S, Johnston ICD, Bosio A, Schauss A and Wild S: A novel multiplex bead-based platform highlights the diversity of extracellular vesicles. J Extracell Vesicles. 5:299752016. View Article : Google Scholar : PubMed/NCBI
28	Brahmer A, Neuberger E, Esch-Heisser L, Haller N, Jorgensen MM, Baek R, Möbius W, Simon P and Krämer-Albers E-M: Platelets, endothelial cells and leukocytes contribute to the exercise-triggered release of extracellular vesicles into the circulation. J Extracell Vesicles. 8:16158202019. View Article : Google Scholar : PubMed/NCBI
29	Giri PK, Kruh NA, Dobos KM and Schorey JS: Proteomic analysis identifies highly antigenic proteins in exosomes from M. tuberculosis-infected and culture filtrate protein-treated macrophages. Proteomics. 10:3190–3202. 2010. View Article : Google Scholar : PubMed/NCBI
