Synchronous thyroid medullary cancer and thyroid hemiagenesis: A case report

Introduction

Thyroid hemiagenesis (TH), which was first reported in 1852, is a rare, congenital anatomical abnormality that is defined as the absence of one thyroid lobe with or without an isthmus (1). In the majority of cases, TH is discovered incidentally when performing imaging of the neck (1). However, to the best of our knowledge, the clinical significance of this malformation has not been fully elucidated. Therefore, to date, there are no clinical recommendations for patients with euthyroidism and TH.

Thyroid cancer is the most common endocrine malignancy (2) and the cancer with the fastest increasing incidence rate worldwide (2); it can be classified into papillary thyroid cancer and follicular thyroid cancer, which are derived from follicular cells. By contrast, medullary thyroid cancer (MTC), another type of thyroid cancer, arise from parafollicular C cells (3). In particular, MTC is a rare type of thyroid cancer and only accounts for 3% of all thyroid malignancies (4,5). The 10-year survival rate of MTC is ~50%, while the 10-year survival rate of differentiated thyroid cancer, including papillary and follicular thyroid cancer, is 94% (5,6). However, the co-occurrence of TH and thyroid cancer is rare, where in the majority of cases co-occurrence presents as synchronous TH and papillary thyroid cancer (7). To date, to the best of our knowledge, only one case of TH and MTC co-occurrence of has been reported (8). In addition, the treatment strategy of concurrent TH and MTC has not been well-illustrated. The present report chronicles a rare case of synchronous TH and MTC and summarizes the epidemiology of the condition, thyroid gland embryology and the treatment strategy for synchronous TH and MTC.

Case report

A 33-year-old man was referred to the thyroid clinic of Weifang People's Hospital (Weifang, China) in May 2022, as a lesion on the left thyroid lobe had been incidentally discovered during a routine health examination 1 month previously. The patient had no personal or family history of endocrine disorders. The patient's physical examination was unremarkable. Laboratory tests (Table I) showed a thyroid-stimulating hormone (TSH) level of 3.4 µU/ml (normal range: 0.5-5.5 µU/ml), serum calcitonin level of 115.2 pg/l (normal range: 0-6.4 pg/l) and serum carcinoembryonic antigen (CEA) level of 30.7 ng/l (normal range: 0-5 ng/l). Laboratory tests results showed that the patient might suffer from MTC.

Table I Summary of patient's laboratory test results.

Table I

Summary of patient's laboratory test results.

Test	Pre-surgery	1-Week post-surgery	1-Month post-surgery
Thyroid-stimulating hormone, µU/ml	3.4	5.6	2.7
Carcinoembryonic antigen, ng/l	30.7	4.2	2.1
Calcitonin, pg/l	115.2	2.6	3.4

Ultrasound of the neck revealed that the left thyroid lobe contained an irregular, hypoechoic, hypervascular tumor with a long diameter of 1.5 cm (Fig. 1A). Cervical CT imaging showed a thyroid tumor located in the left thyroid (Fig. 1B). The right thyroid lobe could not be visualized in the ultrasound and CT images. The patient underwent fine-needle aspiration cytology. The result showed that the morphology of the cells was spindle shaped (Fig. 2) and MTC was suspected. However, ultrasound and CT showed that no suspicious lymph nodes were apparent.

Figure 1 Ultrasonography and CT images of the thyroid. (A) Ultrasonography revealing a hyperechoic nodule (indicated by an asterisk) in the left lobe without the right thyroid lobe. (B) CT imaging showing a solid nodule (indicated by an asterisk) in the left lobe without the right thyroid lobe. CT, computed tomography.

Figure 2 Fine-needle aspiration of the right lobe showing a medullary thyroid tumor.

The patient underwent total thyroidectomy, bilateral central lymph node dissection and left cervical compartment dissection in May 2022. The intraoperative findings indicated right-sided TH and a suspicious lesion (13x12 mm.) in the left thyroid lobe with an isthmus. Tissue specimens were fixed with 4% formalin at room temperature for 12 h, embedded in paraffin at 60˚C for 15 min, cut into 4-µm sections, stained for 5 min at room temperature with hematoxylin and eosin, and observed under a light microscope (Nikon Corporation). On their histopathology under the microscope, the lesion cells were observed to have round nuclei and clumped chromatin with scant amphophilic cytoplasm (Fig. 3). Immunohistochemical analysis of the tissue was performed. Tumor tissue was fixed with 4% neutral formalin at room temperature for 12 h, embedded in paraffin at 60˚C for 15 min, cut into 4-µm sections and sealed with 3% hydrogen peroxide at room temperature for 10 min. Antigen retrieval was performed with EDTA at 100˚C for 2.5 min followed by washing with PBS. Primary antibody incubation was performed at 37˚C for 60 min and secondary antibody incubation at 37˚C for 20 min. The Anti-CEA antibody was purchased from Santa Cruz Biotechnology. The other primary antibodies were purchased from Beyotime Institute of Biotechnology. The following primary antibodies were used: Calcitonin (cat. no. AG8159; 1:100), CEA (sc-48364; cat. no. AF6480; 1:100), thyroid transcription factor 1 (TTF-1; cat. no. AG8751; 1:100) and thyroglobulin (TG; cat. no. AG3385; 1:100). Biotinylated Goat anti-Mouse and Rabbit secondary antibodies were obtained from OriGene Technologies, Inc. (cat. no. PV-6000; 1:500). Immunohistochemical staining results revealed positivity for calcitonin (Fig. 4A), CEA (Fig. 4B) and TTF-1 (Fig. 4C) and negativity forTG) (Fig. 4D). The positivity of calcitonin, CEA and TTF-1 enhanced the diagnosis of MTC, while negative results for TG excluded the diagnosis of differentiated thyroid carcinoma. The lymphatic adipose tissue of the central compartment and the left cervical compartment was dissected. A total of 32 lymph nodes were discovered. Lymph node metastasis was detected in 4 of the 32 lymph node samples harvested.

Figure 3 Histopathology of the lesion indicating a medullary thyroid tumor (hematoxylin and eosin staining; magnification, x200; scale bar, 100 µm).

Figure 4 Immunohistochemical staining of the medullary thyroid cancer indicating that the tumor was (A) positive for calcitonin, (B) positive for carcinoembryonic antigen, (C) positive for TTF-1 and (D) negative for TG (magnification, x200; scale bar, 100 µm). TTF-1, thyroid transcription factor 1.TG, thyroglobulin.

Serum calcitonin and CEA levels dropped to normal 1 week after the surgery (Table I). Replacement therapy with L-thyroxine (100 µg/per day; lifetime) was performed at a TSH level of 0.5-5.5 µU/ml. TSH, calcitonin and CEA were detected every 3 months and follow-up ultrasound was performed every 3 months. The latest follow-up was performed in May 2024. Ultrasound showed no suspicious lymph nodes or recurrent lesions (Fig. 5). Laboratory tests illustrated a TSH level of 3.1 µU/ml, a serum calcitonin level of 2.9 pg/l and a CEA level of 2.5 ng/l.

Figure 5 Ultrasonography showing no recurrent lesion or suspicious lymph node.

Discussion

TH is a rare, congenital abnormality that is defined as the absence of one thyroid lobe with or without an isthmus (1). MTC is a rare malignancy that is derived from neuroendocrine parafollicular C-cells of the thyroid gland (3). To the best of our knowledge, only one case of the co-occurrence of TH and MTC has so far been reported (8).

In the majority of cases, TH is accidentally discovered in patients with other thyroid conditions (9). Previous studies conducted in Northern Poland and Sicily have demonstrated that the prevalence of TH in adolescents is 0.05% (10,11), whereas its prevalence in Belgium in the population with similar demographics is ~0.2% (12). However, children with congenital hypothyroidism in Isfahan (Iran), where goiter and thyroid nodules are prevalent, tend to have a higher TH prevalence at ≤3.7% (13,14). In addition, TH is more common in females, with a female-to-male ratio of 4.3-7:1 (15,16).

MTC is a rare type of thyroid cancer that accounts for 3% of all thyroid malignancies (4,5). Despite its relative rarity, MTC is associated with a significantly higher death rate compared with other types of thyroid cancer, such as papillary and follicular thyroid cancer (5,6).

A previous study has revealed that TH can co-occur with certain benign thyroid conditions, such as Hashimoto's thyroiditis, simple goiters and subacute thyroiditis (8). In addition, TH can co-occurs with other types of thyroid cancer, including papillary and follicular thyroid cancer (8). However, to the best of our knowledge, there is only one reported case of TH and MTC co-occurrence (8). In that report, a 49-year-old woman with MTC and TH underwent a thyroidectomy plus ipsilateral central and lateral neck dissection, and achieved long-term disease-free survival (8). The present study reported another rare case of TH and MTC co-occurrence.

Thyroid embryogenesis is a complex process that remains largely unknown. In addition, to the best of our knowledge, the mechanism underlying the lobulation of the thyroid primordium and controlling the descent of the thyroid gland has not been fully elucidated.

The thyroid gland is the first endocrine organ to develop during gestation. Derived from a medial anlage, it develops between the 3rd and 11th week of gestation (17). Thyroid anlage cells develop because of the proliferation of the endodermal epithelium that lines the floor of the primitive pharynx between the first and second pharyngeal arch (17). Subsequently, this midline structure undergoes numerous transformations, such as enlargement, bifurcation, lobulations and detachment from the pharynx (17). Accompanying the enlargement, the median thyroid anlage is initially hollow and spherical, where then it solidifies, forming follicular elements of the thyroid gland, after which it becomes a bilobed structure (18). During the 5th week of gestation, the lateral thyroid primordia are derived from the ventral part of pharyngeal pouches in the ultimobranchial bodies, where they are attached to the posterior part of the thyroid gland (19). The lateral primordia originate from neural crest cells and provide parafollicular C cells, which produce calcitonin (19). At the end of the 7th week of gestation, the thyroid gland descends in front of the hyoid bone and laryngeal cartilage and then settles in its final position anterior to the trachea (17). Between the 8th and 12th weeks of gestation, the thyroid follicular cells arise from the median thyroid anlage and incorporate iodine (17).

At present, TH is considered to be idiopathic, where theories of its etiology include genetic aberrations, defects in lobulation and failure of descent. A number of transcription factors, such as Forkhead Box Protein E1 (FOXE1), have been shown to be crucial in the proliferation and descent of the thyroid primordial (20-22). In addition, the mutation of these transcription factors (FOXE1, NKX2-1 and PAX8) may induce TH occurrence (20-22).

Regarding the diagnosis, in the majority of cases, TH is typically discovered incidentally during neck imaging. The diagnosis of TH can be confirmed if the contralateral thyroid tissue is revealed by ultrasonography, CT or thyroid scintigraphy (7,23). The combination of ultrasound and scintigraphy or CT is sufficient to confirm the diagnosis of TH (7,23). However, thyroid scintigraphy alone cannot confirm the diagnosis of TH because of the presence of a non-functional hypoplastic lobe, such as in unilateral thyroiditis (7,23). Ultrasound is considered the gold standard imaging modality for diagnosing TH due to its non-invasiveness, low cost and wide availability (7,23). In the present study, ultrasonography and CT showed that the right lobe of thyroid was absence. Therefore, the diagnosis of TH was confirmed.

In general, a cytological smear of a thyroid lesion is the first step in MTC diagnosis (4,5). MTC cells are usually discohesive or weakly cohesive (4,5). The morphology of MTC cells may be spindle-shaped or epithelioid (4,5). However, the diagnosis of MTC via cytological smear is difficult due to a variety of cellular morphologies, non-typical cell shapes and low cellularity (4,5). Serum calcitonin levels of >100 pg/m may further confirm the diagnosis of MTC in ambiguous cases (4,5). In addition, CEA is another reliable tumor marker of MTC (4,5). Pathology is considered to be the gold standard for MTC diagnosis (4,5). On immunohistochemistry, calcitonin, CEA will typically yield positive results, whereas TG should be negative (4,5). In the present case, the serum level of calcitonin and CEA was markedly higher compared with the normal level. MTC markers, including calcitonin and CEA, were positive, confirming the diagnosis of TH and MTC.

Regarding the treatment strategy and follow-up, certain considerations should be made. In general, TH is associated with normal thyroid function, where clinically euthyroid patients should not be treated (7,23). However, TH can be found in association with other thyroid diseases, such as Hashimoto's thyroiditis, Graves' disease and hyperthyroidism (7,23). TH treatment should be performed in accordance with the co-existing thyroid disease. In addition, TH with anatomic abnormalities, including the presence of a thyroglossal cyst or cervical thymic cysts, should be treated in accordance with other congenital diseases (7,23).

For patients with TH and MTC co-occurrence, treatment should be performed in accordance with the MTC treatment guideline (24). Surgery is the first step in MTC treatment and the scope of surgery should include the thyroid gland, bilateral central compartment lymph nodes and lateral neck lymph nodes in accordance with the serum calcitonin level. During follow-up, measuring calcitonin and CEA levels every 3 months is important to determine the chemical relapse of the disease. In addition, neck ultrasonography should be performed every 3 months to check for MTC relapse. In the present case, the patient remains healthy with no evidence of disease recurrence.

Notably, the present case has certain limitations. The pathology and clinical significance of TH were not completely illustrated. Therefore, gene mutation and epigenetic changes of TH require further investigation. Furthermore, the association between TH and other thyroid diseases has not been well-studied. In future studies, high-throughput technologies may discover the cause of TH in thyroid embryogenesis and the relationship between TH and other thyroid diseases.

In conclusion, TH is a rare congenital anomaly that is typically asymptomatic. MTC occurrence in the remnant lobe is uncommon. Knowledge of this rare type of thyroid disorder and immunohistochemical markers are key to making a correct diagnosis. The treatment strategy for TH and MTC co-occurrence should follow the MTC guideline.
