Sub‑classification of non‑inflammatory and inflammatory surgical aortic aneurysms and the association of histological characteristics with potential risk factors
Affiliations: Department of Cardiovascular Surgery, , Department of Morpho‑Functional Sciences-Pathophysiology, , Department of Internal Medicine-Legal Medicine, , Department of Morpho‑Functional Sciences-Pathology,
- Published online on: August 16, 2019 https://doi.org/10.3892/etm.2019.7903
- Pages: 3046-3052
Copyright: © Butcovan et al. This is an open access article distributed under the terms of Creative Commons Attribution License.
This article is mentioned in:
Diagnostics in aortic pathology require more attention (1,2) and little is known about the histological patterns of aortic pathology with regard to medial degeneration (MD), atherosclerosis (ATS) and aortitis in relation to potential risk factors as well as to their distribution in different aortic segments. While MD is reported to be the leading histological finding in cases of aneurysm, the roles of ATS and inflammatory processes seem to be underestimated (3,4). A clinical manifestation of all these aortic lesions is an aortic aneurysm. As a permanent dilatation of the aortic wall, an aortic aneurysm may affect all aortic segments, including the thoracic aorta and abdominal aorta (5). These aneurysms are classified according with involved aortic segments, such as aortic root, ascending aorta, arch, or descending aorta for thoracic aneurysms and suprarenal, juxtarenal and infrarenal aorta for abdominal aneurysms (1). The etiology, natural history, histology and treatment differ for each of these aneurysms segments, because the aorta is subject to a variety of diseases, degenerative, inflammatory, infectious and idiopathic (3).
The aim of the present study was to assess aortic aneurysms, including MD, ATS and inflammatory processes, according to the newest consensus documents on non-inflammatory and inflammatory aortic pathology (6–8) in association with potential risk factors.
Materials and methods
The intraoperative specimens of the entire aorta were obtained from 52 patients recruited between March 2015 and September 2016. The specimens included 39 thoracic aortic aneurysm (TAA) and 13 abdominal aortic aneurysm (AAA) samples from 38 men (73%) and 14 women (27%) with ages ranging between 19 and 80 years (average, 61.7 years). The specimens were recovered during open aortic surgery. The patients with TAA and severe aortic valve incompetence underwent ascending aortic replacement. Surgically, the sinotubular junction was remodelated using Dacron grafts and the aortic valve plane was relocated. The basic goal of surgical repair of AAA was the exclusion of the aortic aneurysm from the systemic circulation with preservation of blood flow to the pelvis and legs via an implanted new bifurcated graft (Hemashield Platinum).
The individual clinical data [age, sex, hypertension (HTA), smoking, history of the aortic disease and previous inflammatory processes] were obtained from medical records. The present study was conducted according to the Helsinki Declaration and approved by the Institutional Review Committee at The ‘Prof. Dr. George Georgescu’, Institute of Cardiovascular Diseases. Written informed consent was signed by all patients.
For histological studies, AAT and AAA were fixed with 10% neutral buffered formalin solution (at room temperature, 24 h) and embedded in paraffin. Cross-sections of aortic tissue (4 µm) were stained with hematoxylin and eosin for tissue morphology. Elastic Van Gieson's staining (at room temperature, 55 min) was used to analyze elastic fibers. The histological assessment was performed by an experienced pathologist using an optical microscope (CX41; Olympus Corporation; magnifications, ×40, ×100, ×200 and ×400). The measurements were visualized using color image analysis software (QuickPHOTO MICRO 3.0; PROMICRA, s.r.o.).
To optimize the histological diagnosis, standardized nomenclature was applied, according to consensus documentation referring to unified nomenclature for a variety of non-inflammatory degenerative aortic lesions (8) for the histological analysis of the aorta specimens. ATS lesions were present in both TAA and AAA cases, presenting various degrees of severity with consequent aortic wall changes. The severity of the atherosclerotic lesions in surgically resected segments of the aorta was graded according to Stone et al (7): i) 1, mild-1; ii) 2, moderate; and iii) 3, severe.
Data were analyzed using IBM SPSS Statistics 21 Software and results were expressed as mean ± standard deviation and percentages. The correlations between non-inflammatory degenerative aortic lesions and potential atherosclerotic risk factors (age>65 years, male sex, smoking, arterial hypertension, and bicuspid aortic valve) were evaluated by Kendall's tau-b coefficient correlation with P<0.05 being significant.
An aneurysm is defined as a dilatation of ≥50% above the normal diameter of an artery
Of the total number of patients with aortic aneurysms who underwent aortic dilation, thoracic aorta was the most commonly involved segment (n=39), while abdominal aorta was only identified in one-third of cases (n=13); the two aortic segments demonstrated different etiologies. Aortic aneurysms have a multifactorial etiology. The multiple risk factors included advanced age, male, smoking, HTA, ATS and bicuspid aortic valve (BAV) (Table I).
Comparative analysis of risk factors and histological characteristics in patients with surgical aortic aneurysms.
The average patient age for TAA was 55.6 years in males and 50.6 years in females and the average patient age for AAA was 69.7 years in males and 71.2 years in females. From the entire aortic aneurysm group (n=52), males were predominant in both the TAA group (79.5%; 31 of 39 patients) and the AAA group (69.2%; 9 of 13 patients).
Of the risk factors, smoking was a more common finding in TAA (56.4%; n=22) than in AAA (46.2%; n=6). Similarly, HTA registered higher values in TAA (33.3%; n=13) than in AAA (23.1%; n=3). BAV was found only in five of the TAA cases (12.8%) in association with aortic regurgitation. No genetic disorder history was identified in the study group patients.
Histopathological examination revealed only MD lesions (64.1%, 25 of 39 patients), ATS lesions (23.1%, 9 of 39 patients), mixed lesions, MD and ATS (17.9%, 7 of 39 patients) in patients with TAA (n=39), and microscopically proven aortitis (12.8%, 5 of 39 patients) in TAA, while in patients with AAA (n=13) only ATS lesions (100%) were present (Table I).
MD lesions in aortic aneurysms
A total of 32 (82.1%) cases of MD (only lesions or together with ATS lesions) were identified in the patients with TAA. Of all these lesions, 3 (12%) were with mild medial degeneration (mMD), 17 (43.6%) with moderate medial degeneration (MMD) and 12 (48%) with severe medial degeneration (SMD) (Fig. 1).
Aortic MD. Tissues of (A) grade 1, (B) grade 2 and (C) grade 3, were determined via Elastic Van Gieson's staining (magnification ×100). MD, medial degeneration.
In the patients with TAA with mMD aortic lesions (grade 1), the aortic medial wall showed a multifocal decrease in the number of smooth muscle cells (SMCs) with minimal collagen deposition, a decrease in number of the elastic fibers (EF) and multifocal, mild EF fragmentation associated with focal, mild intralamellar mucoid accumulation (Fig. 1A).
In the patients with TAA with MMD aortic lesions (grade 2), the aortic wall had a decreased number of SMCs and multifocal mild substitutive fibrosis, a reduction in the number of EFs and multifocal moderate EF fragmentation with formation of multifocal, moderate intralamellar and focal, translamellar mucoid accumulation (Fig. 1B).
In the patients with TAA with SMD aortic lesions (grade 3) the medial aortic wall showed extensive, band-like SMC loss, multifocal moderate EF fragmentation and multifocal severe translamellar mucoid accumulation (Fig. 1C).
In our study, the medial degenerative aortic lesions (mild=1, moderate=2, and severe=3) significantly correlated with advanced age (>65 years) (r=−0.39, P<0.01) and male sex (r=0.27, P<0.05; Table II).
Kendall's Tau-b correlation coefficient of degenerative, atherosclerotic and inflammatory lesions with potential risk factors in aortic aneurysm (n=52).
Atherosclerotic lesions in aortic aneurysms
The atherosclerotic aneurysms were found in 22 patients, 13 (9 males, 4 females) were abdominal and 9 (6 males, 3 females) were thoracic aneurysms. In the AAAs, all atherosclerotic lesions were severe (grade 3), with fibrotic changes of the entire wall, with or without associated complications. In the TAAs, most cases had MMD or SMD associated with intimal atherosclerotic lesions of different types (grades 1–2), with the formation of mixed, degenerative-atherosclerotic aneurysms (7 cases). A total of 2 patients with TAA with pure ATS lesions (mild) were identified. In most AAA cases, adventitial inflammation was also observed. The present results revealed early atherosclerotic lesions in the thoracic aorta (Fig. 2A) and advanced atherosclerotic lesions in the abdominal aorta (Fig. 2B).
Aortic atherosclerotic aneurysms. Images of (A) mixed thoracic aortic and (B) atherosclerotic aortic aneurysms (black arrow, atherosclerotic plaque). Sections were examined via Elastic Van Gieson's staining (magnification, ×100). a, atherosclerotic plaque; b, medial degenerative lesion.
Kendall's tau-b correlation shows that the atherosclerotic aortic lesions (1, mild; 2, moderate; and 3, severe) significantly correlated with advanced age (>65 years) (r=−0.40, P<0.01) and smoking (r=−0.29, P<0.05; Table II).
Inflammation in aortic aneurysms
In total, 5 patients with TAA had aortitis, determined by histological examination, including three giant cell aortitis (GCA) cases, one Takayasu aortitis (TA) case and one patient with syphilitic aortitis. The aortitis group included 3 men and 2 women. The GCA cases consisted of 2 males and 1 female with an average age of 62.5 years (ranging between 52 and 70 years); the patient with TA was a 36-year-old female and the patient with syphilitic aortitis was a 56-year-old male.
In all five TAA aortitis cases, the mean pre-operative erythrocyte sedimentation rate was 31.5 mm/h, and for C-reactive protein was 21.6 mg/d. Of the 5 patients, 1 (20%) needed coronary artery bypass grafting, 3 (60%) underwent aortic valve surgery (1 aortic valve repair and 2 aortic valve replacement), and all 5 (100%) required aortic surgery (ascending aortic replacement).
In most aortitis cases (60%) the diagnosis was made after the operation based on histopathologic examination, except TA where the examination suggested pre-operatory TA disease, and syphilitic aortitis where the patient had a history of syphilis.
The common histological features in granulomatous aortitis were: i) Diffuse intimal hyperplasia, granulomatous inflammation in the media comprised of epithelioid macrophages and occasional giant cells related by ‘laminar medial necrosis’, areas of smooth muscle cell loss with collapsed elastic fibers, fibrotic scars and an adventitial accompanying lymphoplasmacytic infiltrate in GCA (Fig. 3A); and ii) diffuse intimal hyperplasia, compact granulomas and medial necrosis, scarring in the tunica media with disruption and disorganization of the remaining elastic fibers, and dense adventitial fibrosis in TA (Fig. 3B).
Non-infectious aortitis. (A) Giant cell aortitis with micronodular granulomas at the inner half of the media (arrows) and less adventitial fibrosis (determined via Elastic Van Gieson's staining; magnification, ×100). (B) Takayasu aortitis with medial giant cell granuloma (arrow) and more adventitial fibrosis (determined via Elastic Van Gieson's staining; magnification, ×400).
Among the 5 aortitis cases, one was diagnosed with syphilitic aortitis on the basis of the pathological features and patient history. A man in his 50 s, who presented valvular regurgitation, aneurysmal disease and myocardial ischemia, also required coronary artery bypass grafting surgery. All these lesions were cardiovascular complications of syphilis involving the aorta (leading to the formation of aneurysms and aortic-valve incompetence) and coronary artery, causing coronary ostial stenosis (angina pectoris complaints). The histopathological examination revealed a chronic mesoaortitis, characterized by normal media replacement with fibrous scars and adventitial endarteritis of the vasa vasorum (Fig. 4).
Endarteritis obliterans of the vasa vasorum and medial scar (determined via Elastic Van Gieson's staining; magnification, ×100). The black arrow indicates adventiceal vasa vasorum with a very thick wall and slit-like stenotic lumen.
An aortic aneurysm is defined as a dilatation of an aortic segment with a diameter of at least one and one-half times the normal diameter (8). Aortic aneurysms can involve the ascending aorta or descending aorta. In the present study, the aortic aneurysms included 39 (75%) thoracic and 13 (25%) abdominal cases. Other previous epidemiology studies reported that AAA involves mainly older patients, while TAA involves mainly two populations: One of old age with no special history (9) and another of young age suffering from connective tissue disorders, including Marfan's syndrome (10). Marfan's syndrome or connective tissue disorders were not detected in the young patients with TAA in the present study (11,12). Good familial history, histopathological examination and genetic screening are important factors that require consideration.
In agreement with Hiratzka et al (13), the present study identified that the most common risk factors for the development of aortic aneurysm were advanced age (>65 years old), male, smoking, high blood pressure and family history. The potential risk factors identified to be associated with aortic aneurysm development were advanced age, HTA and BAV in TAA, and advanced age, male, smoking and ATS in AAA.
Previous studies reported that TAAs are most often associated with MD, which can be regarded as a structural alteration responsible for the development of aortic aneurysms in relation to other risk factors (8,14). In the present study, the histopathological profile showed that MD was the most common histopathological substrate in TAA (82.1%), granulomatous aortitis (10.25%) was a rare cause of TAA and syphilitic aortitis (2.5%) was a very rare encountered case, and ATS was a common histopathological substrate in AAA (100%).
In patients with aortic aneurysms, histological analysis of the aortic resection specimens provides important diagnostic information on the MD lesions, describing a definite pattern of distribution of MD severity within the aortic wall. Moreover, aortitis was an unexpected diagnosis during the histological examination of surgically resected aortic thoracic aneurysms in patients without clinical signs or symptoms of systemic vasculitis. Aortic thoracic aneurysm is in most cases a fatal condition, especially in association with more severe degenerative changes in the aortic media.
GCA and TA, diagnosed in the present study, are considered the most common causes of non-infectious aortitis (8). Garcia-Martinez et al (15) observed that ≥20% of patients with GCA and 50% of patients with TA would develop changes consistent with aneurysmal aortitis, while in the present study, it was identified that only 7.6% of patients with GCA had TAA and 2.5% patients with TA had TAA, the remaining one TAA case having syphilitic aortitis.
Histopathological examination is not sufficient to distinguish between the two conditions, and, together with clinical data, it must be integrated within a diagnostic algorithm. In the final diagnosis, American College of Rheumatology (ACR) criteria were applied and at least three ACR criteria, including clinical, imagistic and histological data, were present to confirm the two granulomatous aortitis (16,17).
In the present study, syphilitic aortitis was a rare cause of AA from all the TAA cases. In agreement with Vaideeswar (18), the complications in the form of aortic aneurysms and insufficiency in association with coronary ostial stenosis frequently coexist in the tertiary syphilis. For diagnosis, not only the pathological findings but also the clinical features and serology should be taken into consideration.
The present study also included 20 cases of atherosclerotic lesions. The clinical analysis of the 20 AAs revealed two types of aneurysmal diseases, 7 (35%) mixed TAAs and 13 (65%) ATS AAAs. The present results are in agreement with Singh et al (19), who noted that abdominal aneurysms account for the majority of aortic aneurysms. In the present study, the histopathological examination revealed intimal atheroma and parietal thrombosis in both AAA and aortic ATS, similar to the consensus statement on surgical pathology (20). The presence of ATS lesions in both groups may suggest the need for ATS medical therapy in all patients with TAA and AAA. Due to the highest degree of severity of the ATS AAA lesions, it was suggested that ATS plays an important role in AAA development.
In the present study, mixed TAA was associated with two lesions, MD and atherosclerotic lesions. However, additional marked elastin fragmentation and adventitial chronic inflammation were mainly restricted to AAA. Peshkova et al (21) identified that ATS changes in the aortic wall underlie AAA formation, where local inflammation contributes to aortic wall thickening. From the present results, it was hypothesized that abundant inflammatory infiltrate represents a common trigger for ATS and AAA development and extension. Additionally, the present results suggested that inflammation is a risk factor in AAA rupture, revealing the importance of anti-inflammatory medication in reducing AAA complications in patients.
The present study had a number of limitations, including a small group of patients with advanced aortic disease and no genetic studies. The small number of patients did not allow for more extensive statistical studies. The present study reflects morphoclinical particularities of aortic aneurysms in the geographical area. Further studies with larger biomarker panels are required to determine associations with other factors.
In conclusion, the present study provided insight for the development of aortic aneurysm evaluation for detecting and monitoring AAA and TAA in affected patients. The present study provides insight for the inclusion of histopathological examination in the final diagnosis, in consensus with the late knowledge and classification of aortic surgical pathology for diagnosis optimization. Prospective studies using large study groups will be necessary to further histologically evaluate the extent and severity of the disease and its progression.
No funding was received.
Availability of data and materials
All data generated or analyzed during this study are included in this published article.
GT and DB conceived and designed the current study. DB, GT, MD and BGI performed the experiments. DB, MD, REH and VM collected and analyzed the data. DB, GT and VM wrote the manuscript. All authors read and approved the final version of the manuscript.
Ethics approval and consent to participate
The present study was performed in accordance with the ethical standards of the Declaration of Helsinki and was approved by the Research Ethics Committee of Professor George Georgescu Institute of Cardiovascular Diseases, Iasi, Romania (approval no. 974/17.02.2015). Informed consent was obtained from all individual participants included in the current study.
Patient consent for publication
The authors declare that they have no competing interests.
