Detection assay for HPV16 and HPV18 by loop‑mediated isothermal amplification with lateral flow dipstick tests

Kumvongpin,Ratchanida; Jearanaikoon,Patcharee; Wilailuckana,Chotchana; Sae‑Ung,Nattaya; Prasongdee,Prinya; Daduang,Sakda; Wongsena,Metee; Boonsiri,Patcharee; Kiatpathomchai,Wansika; Swangvaree,Sukumarn Sanersak; Sandee,Alisa; Daduang,Jureerut

doi:10.3892/mmr.2017.6370

Detection assay for HPV16 and HPV18 by loop‑mediated isothermal amplification with lateral flow dipstick tests

Authors:
- Ratchanida Kumvongpin
- Patcharee Jearanaikoon
- Chotchana Wilailuckana
- Nattaya Sae‑Ung
- Prinya Prasongdee
- Sakda Daduang
- Metee Wongsena
- Patcharee Boonsiri
- Wansika Kiatpathomchai
- Sukumarn Sanersak Swangvaree
- Alisa Sandee
- Jureerut Daduang
View Affiliations

Affiliations: Centre for Research and Development of Medical Diagnostic Laboratories, Faculty of Associated Medical Sciences, Khon Kaen University, Khon Kaen 40002, Thailand, Division of Pharmacology and Toxicology, Faculty of Pharmaceutical Sciences, Khon Kaen University, Khon Kaen 40002, Thailand, Ubon Ratchathani Cancer Center, Ubon Ratchathani 34000, Thailand, Department of Biochemistry, Faculty of Medicine, Khon Kaen University, Khon Kaen 40002, Thailand, Bioengineering and Sensing Technology Laboratory, BIOTEC, National Science and Technology Development Agency, Khlong Luang, Pathum Thani 12120, Thailand, Gynecological Oncology Division, National Cancer Institute, Bangkok 10400, Thailand, Chulabhorn Research Institute, Bangkok 10210, Thailand
Published online on: March 23, 2017 https://doi.org/10.3892/mmr.2017.6370
Pages: 3203-3209

Metrics: Total Views: 0 (Spandidos Publications: | PMC Statistics: )

Metrics: Total PDF Downloads: 0 (Spandidos Publications: | PMC Statistics: )

Cited By (CrossRef): 0 citations Loading Articles...

Abstract

Cervical cancer is the third highest cause of death in developing countries and most commonly results from high‑risk human papillomavirus (HR‑HPV) infection. Among HR‑HPV genotypes, HPV16 and HPV18 are the most prevalent in cervical cancers. Therefore, the present study aimed to develop a detection assay for HPV16 and HPV18 infection using loop‑mediated isothermal amplification (LAMP) with lateral flow dipstick (LFD) tests. This assay is a simplified, user‑friendly method for the visual detection of HPV genotypes. DNA was extracted from clinical tissue samples, and HPV genotyping was performed using nested polymerase chain reaction (PCR). The clinical samples were demonstrated to include 44 HPV16‑positive, 18 HPV18‑positive and 80 HPV‑negative samples. All DNA samples were also used as templates for a LAMP reaction (30 min at 65˚C), and subsequently, a fluorescein isothiocyanate‑labelled probe was hybridized with the reaction product. Finally, the LFD test was performed. The sensitivity of the LAMP‑LFD test was higher than LAMP‑turbidity, exhibiting up to 100‑fold higher sensitivity for HPV16 and 10‑fold higher sensitivity for HPV18. All HPV16 and HPV18‑positive samples generated positive results in both assays; however, 22 samples detected as HPV‑negative by LAMP‑turbidity exhibited positive results by LAMP‑LFD test (22 of 80 samples). Therefore, these samples were further examined using quantitative (q)PCR. The results demonstrated that 20 out of the 22 samples designated positive by LAMP‑LFD, but negative by LAMP turbidity, gave a positive result with qPCR, while the remaining 2 samples were negative by qPCR. The present results suggested that LAMP‑LFD provided higher sensitivity than LAMP‑turbidity and nested PCR. Thus, the LAMP‑LFD test developed in the present study might be useful for the detection of HPV16 and HPV18 in local hospitals.

View Figures

View References

1	Torre LA, Bray F, Siegel RL, Ferlay J, Lortet-Tieulent J and Jemal A: Global cancer statistics, 2012. CA Cancer J Clin. 65:87–108. 2015. View Article : Google Scholar : PubMed/NCBI
2	Chansaenroj J, Junyangdikul P, Chinchai T, Swangvaree S, Karalak A, Gemma N and Poovorawan Y: Large scale study of HPV genotypes in cervical cancer and different cytological cervical specimens in Thailand. J Med Virol. 86:601–607. 2014. View Article : Google Scholar : PubMed/NCBI
3	Suthipintawong C, Siriaunkgul S, Tungsinmunkong K, Pientong C, Ekalaksananan T, Karalak A, Kleebkaow P, Vinyuvat S, Triratanachat S, Khunamornpong S and Chongsuwanich T: Human papilloma virus prevalence, genotype distribution, and pattern of infection in Thai women. Asian Pac J Cancer Prev. 12:853–856. 2011.PubMed/NCBI
4	Saslow D, Solomon D, Lawson HW, Killackey M, Kulasingam SL, Cain J, Garcia FA, Moriarty AT, Waxman AG, Wilbur DC, et al: American cancer society, American society for colposcopy and cervical pathology and American society for clinical pathology screening guidelines for the prevention and early detection of cervical cancer. CA Cancer J Clin. 62:147–172. 2012. View Article : Google Scholar : PubMed/NCBI
5	Arney A and Bennett KM: Molecular diagnostics of human papillomavirus. Labmedicine. 41:523–530. 2010.
6	Zaravinos A, Mammas IN, Sourvinos G and Spandidos DA: Molecular detection methods of human papillomavirus (HPV). Int J Biol Marker. 24:215–222. 2009. View Article : Google Scholar
7	Notomi T, Okayama H, Masubuchi H, Yonekawa T, Watanabe K, Amino N and Hase T: Loop-mediated isothermal amplification of DNA. Nucleic Acids Res. 28:E632000. View Article : Google Scholar : PubMed/NCBI
8	Saetiew C, Limpaiboon T, Jearanaikoon P, Daduang S, Pientong C, Kerdsin A and Daduang J: Rapid detection of the most common high-risk human papillomaviruses by loop-mediated isothermal amplification. J Virol Methods. 178:22–30. 2011. View Article : Google Scholar : PubMed/NCBI
9	Fischbach J, Xander NC, Frohme M and Glokler JF: Shining a light on LAMP assays-a comparison of LAMP visualization methods including the novel use of berberine. Biotechniques. 58:189–194. 2015. View Article : Google Scholar : PubMed/NCBI
10	Posthuma-Trumpie GA, Korf J and van Amerongen A: Lateral flow (immuno)assay: Its strengths, weaknesses, opportunities and threats. A literature survey. Anal Bioanal Chem. 393:569–582. 2009. View Article : Google Scholar : PubMed/NCBI
11	Yetisen AK, Akram MS and Lowe CR: Paper-based microfluidic point-of-care diagnostic devices. Lab Chip. 13:2210–2251. 2013. View Article : Google Scholar : PubMed/NCBI
12	Sotlar K, Diemer D, Dethleffs A, Hack Y, Stubner A, Vollmer N, Menton S, Menton M, Dietz K, Wallwiener D, et al: Detection and typing of human papillomavirus by e6 nested multiplex PCR. J Clin Microbiol. 42:3176–3184. 2004. View Article : Google Scholar : PubMed/NCBI
13	de Villiers EM: Papillomavirus and HPV typing. Clin Dermatol. 15:199–206. 1997. View Article : Google Scholar : PubMed/NCBI
14	Kiatpathomchai W, Jaroenram W, Arunrut N, Jitrapakdee S and Flegel TW: Shrimp Taura syndrome virus detection by reverse transcription loop-mediated isothermal amplification combined with a lateral flow dipstick. J Virol Methods. 153:214–217. 2008. View Article : Google Scholar : PubMed/NCBI
15	Kumvongpin R, Jearanaikool P, Wilailuckana C, Sae-ung N, Prasongdee P, Daduang S, Wongsena M, Boonsiri P, Kiatpathomchai W, Swangvaree SS, et al: High sensitivity, loop-mediated isothermal amplification combined with colorimetric gold-nanoparticle probes for visual detection of high risk human papillomavirus genotypes 16 and 18. J Virol Methods. 234:90–95. 2016. View Article : Google Scholar : PubMed/NCBI
16	Peitsaro P, Johansson B and Syrjänen S: Integrated human papillomavirus type 16 is frequently found in cervical cancer precursors as demonstrated by a novel quantitative real-time PCR technique. J Clin Microbiol. 40:886–891. 2002. View Article : Google Scholar : PubMed/NCBI
17	Damay A, Didelot-Rousseau MN, Costes V, Konate I, Ouedraogo A, Nagot N, Foulongne V, Van de Perre P, Mayaud P and Segondy M: Viral load and physical status of human papillomavirus (HPV) 18 in cervical samples from female sex workers infected with HPV 18 in Burkina Faso. J Med Virol. 81:1786–1791. 2009. View Article : Google Scholar : PubMed/NCBI
18	Wanga X, Tenga D, Guana Q, Tiana F and Wang J: Detection of roundup ready soybean by loop-mediated isothermal amplification combined with a lateral-flow dipstick. Food Cont. 29:213–220. 2013. View Article : Google Scholar
19	Notomi T, Mori Y, Tomita N and Kanda H: Loop-mediated isothermal amplification (LAMP): Principle, features, and future prospects. J Microbiol. 53:1–5. 2015. View Article : Google Scholar : PubMed/NCBI
20	Mori Y, Hirano T and Notomi T: Sequence specific visual detection of LAMP reactions by addition of cationic polymers. BMC Biotechnol. 6:32006. View Article : Google Scholar : PubMed/NCBI
21	Kaewphinit T, Arunrut N, Kiatpathomchai W, Santiwatanakul S, Jaratsing P and Chansiri K: Detection of Mycobacterium tuberculosis by using loop-mediated isothermal amplification combined with a lateral flow dipstick in clinical samples. Biomed Res Int. 2013:9262302013. View Article : Google Scholar : PubMed/NCBI
22	Khunthong S, Jaroenram W, Arunrut N, Suebsing R, Mungsantisuk I and Kiatpathomchai W: Rapid and sensitive detection of shrimp yellow head virus by loop-mediated isothermal amplification combined with a lateral flow dipstick. J Virol Methods. 188:51–56. 2013. View Article : Google Scholar : PubMed/NCBI
23	Kil EJ, Kim S, Lee YJ, Kang EH, Lee M, Cho SH, Kim MK, Lee KY, Heo NY, Choi HS, et al: Advanced loop-mediated isothermal amplification method for sensitive and specific detection of Tomato chlorosis virus using a uracil DNA glycosylase to control carry-over contamination. J Virol Methods. 213:68–74. 2015. View Article : Google Scholar : PubMed/NCBI
