NF‑κB inhibitor DHMEQ inhibits titanium dioxide nanoparticle‑induced interleukin‑1β production: Inhibition of the PM2.5‑induced inflammation model

Fukatsu,Hitomi; Koide,Naoki; Tada‑Oikawa,Saeko; Izuoka,Kiyora; Ikegami,Akihiko; Ichihara,Sahoko; Ukaji,Tamami; Morita,Naoko; Naiki,Yoshikazu; Komatsu,Takayuki; Umezawa,Kazuo

doi:10.3892/mmr.2018.9533

NF‑κB inhibitor DHMEQ inhibits titanium dioxide nanoparticle‑induced interleukin‑1β production: Inhibition of the PM2.5‑induced inflammation model

Authors:
- Hitomi Fukatsu
- Naoki Koide
- Saeko Tada‑Oikawa
- Kiyora Izuoka
- Akihiko Ikegami
- Sahoko Ichihara
- Tamami Ukaji
- Naoko Morita
- Yoshikazu Naiki
- Takayuki Komatsu
- Kazuo Umezawa
View Affiliations

Affiliations: Department of Molecular Target Medicine, Aichi Medical University, Nagakute, Aichi 480‑1195, Japan, Department of Microbiology and Immunology, Aichi Medical University, Nagakute, Aichi 480‑1195, Japan, School of Life Studies, Sugiyama Jogakuen University, Nagoya, Aichi 464‑8662, Japan, Graduate School of Regional Innovation Studies, Mie University, Tsu, Mie 514‑8507, Japan, Department of Environmental and Preventive Medicine, Jichi Medical University, Shimotsuke, Tochigi 329‑0498, Japan
Published online on: October 3, 2018 https://doi.org/10.3892/mmr.2018.9533
Pages: 5279-5285

Metrics: Total Views: 0 (Spandidos Publications: | PMC Statistics: )

Metrics: Total PDF Downloads: 0 (Spandidos Publications: | PMC Statistics: )

Cited By (CrossRef): 0 citations Loading Articles...

Abstract

PM2.5 is a particle with a diameter <2.5 µm that is often involved in air pollution. Nanoparticles <100 nm are thought to invade the trachea and lungs to cause inflammation, possibly through the activation of macrophages. On the other hand, titanium dioxide (TiO2) particles can be used in models of nano‑micro‑sized particles, as one can prepare the particles with such sizes. TiO2 particles are classified into Rutile, Anatase, and Brookite types by their crystal structure. Among them, Anatase‑type TiO2 particles with a primary diameter of 50 nm (A50) were reported to induce interleukin (IL)‑1β production and secretion effectively in phorbol 12‑myristate 13‑acetate‑treated human monocytic leukemia THP‑1 cells (THP‑1 macrophages). We previously designed and synthesized dehydroxymethyl‑epoxyqinomicin (DHMEQ) as an inhibitor of NF‑κB. The present study investigated whether the NF‑κB inhibitor DHMEQ inhibits TiO2 nanoparticle‑induced IL‑1β production in THP‑1 macrophages, and determined the mechanism. As a result, DHMEQ inhibited A50‑induced IL‑1β secretion in ELISA assays at nontoxic concentrations. It decreased the expression of IL‑1β mRNA, which was dependent on NF‑κB. Although NLR family pyrin domain containing 3 (NLRP3)‑inflammasome‑caspase‑1 activation is required for the maturation of IL‑1β, and DHMEQ reduced the NLRP3 mRNA expression and caspase‑1 activity; a caspase‑1 inhibitor did not influence the A50‑induced IL‑1β production. Therefore, it is likely that inhibition of pro‑IL‑1β expression by DHMEQ may be sufficient to inhibit mature IL‑1β production. Thus, DHMEQ may be useful for the amelioration of inflammation in the trachea and lungs caused by inhalation of PM2.5.

View Figures

View References

1	Brook RD, Franklin B, Cascio W, Hong Y, Howard G, Lipsett M, Luepker R, Mittleman M, Samet J, Smith SC Jr, et al: Air pollution and cardiovascular disease: A statement for healthcare professionals from the expert panel on population and prevention science of the American heart association. Circulation. 109:2655–2671. 2004. View Article : Google Scholar : PubMed/NCBI
2	Nel AE, Mädler L, Velegol D, Xia T, Hoek EM, Somasundaran P, Klaessig F, Castranova V and Thompson M: Understanding biophysicochemical interactions at the nano-bio interface. Nat Mater. 8:543–557. 2009. View Article : Google Scholar : PubMed/NCBI
3	Morimoto Y and Tanaka I: Effects of nanoparticles on humans. Sangyo Eiseigaku Zasshi. 50:37–48. 2008.(In Japanese). View Article : Google Scholar : PubMed/NCBI
4	Adachi T, Takahara K, Taneo J, Uchiyama Y and Inaba K: Particle size of latex beads dictates IL-1β production mechanism. PLoS One. 8:e684992013. View Article : Google Scholar : PubMed/NCBI
5	Tada-Oikawa S, Ichihara G, Fukatsu H, Shimanuki Y, Tanaka N, Watanabe E, Suzuki Y, Murakami M, Izuoka K, Chang J, et al: Titanium dioxide particle type and concentration influence the inflammatory response in Caco-2 cells. Int J Mol Sci. 17:5762016. View Article : Google Scholar : PubMed/NCBI
6	Matsumoto N, Ariga A, To-e S, Nakamura H, Agata N, Hirano S, Inoue J and Umezawa K: Synthesis of NF-kappaB activation inhibitors derived from epoxyquinomicin C. Bioorg Med Chem Lett. 10:865–869. 2000. View Article : Google Scholar : PubMed/NCBI
7	Ariga A, Namekawa J, Matsumoto N, Inoue J and Umezawa K: Inhibition of tumor necrosis factor-alpha-induced nuclear translocation and activation of NF-kappaB by dehydroxymethylepoxyquinomicin. J Biol Chem. 277:24625–24630. 2002. View Article : Google Scholar : PubMed/NCBI
8	Yamamoto M, Horie R, Takeiri M, Kozawa I and Umezawa K: Inactivation of NF-kappaB components by covalent binding of (−)-dehydroxymethylepoxyquinomicin to specific cysteine residues. J Med Chem. 51:5780–5788. 2008. View Article : Google Scholar : PubMed/NCBI
9	Takeiri M, Horie K, Takahashi D, Watanabe M, Horie R, Simizu S and Umezawa K: Involvement of DNA binding domain in the cellular stability and importin affinity of NF-κB component RelB. Org Biomol Chem. 10:3053–3059. 2012. View Article : Google Scholar : PubMed/NCBI
10	Shimada C, Ninomiya Y, Suzuki E and Umezawa K: Efficient cellular uptake of the novel NF-kappaB inhibitor (−)-DHMEQ and irreversible inhibition of NF-kappaB in neoplastic cells. Oncol Res. 18:529–535. 2010. View Article : Google Scholar : PubMed/NCBI
11	Kozawa I, Kato K, Teruya T, Suenaga K and Umezawa K: Unusual intramolecular N->O acyl group migration occurring during conjugation of (−)-DHMEQ with cysteine. Bioorg Med Chem Lett. 19:5380–5382. 2009. View Article : Google Scholar : PubMed/NCBI
12	Umezawa K: Peritoneal NF-κB as a possible molecular target for suppression of various cancers and inflammation. ForumImmun Dis Ther. 4:63–77. 2013. View Article : Google Scholar
13	Lin Y, Ukaji T, Koide N and Umezawa K: Inhibition of late and early phases of cancer metastasis by NF-κB inhibitor DHMEQ derived from microbial bioactive metabolite epoxyquinomicin: A review. Int J Mol Sci. 19:7292018. View Article : Google Scholar :
14	Suzuki E and Umezawa K: Inhibition of macrophage activation and phagocytosis by a novel NF-kappaB inhibitor, dehydroxymethylepoxyquinomicin. Biomed Pharmacother. 60:578–586. 2006. View Article : Google Scholar : PubMed/NCBI
15	Suzuki E, Sugiyama C and Umezawa K: Inhibition of inflammatory mediator secretion by (−)-DHMEQ in mouse bone marrow-derived macrophages. Biomed Pharmacother. 63:351–358. 2009. View Article : Google Scholar : PubMed/NCBI
16	Sosińska P, Baum E, Maćkowiak B, Staniszewski R, Jasinski T, Umezawa K and Bręborowicz A: Inhibition of NF-kappaB with dehydroxyepoxiquinomicin modifies function of human peritoneal mesothelial cells. Am J Transl Res. 8:5756–5765. 2016.PubMed/NCBI
17	Suzuki Y, Sugiyama C, Ohno O and Umezawa K: Preparation and biological activities of optically active dehydroxymethylepoxyquinomicin, a novel NF-κB inhibitor. Tetrahedron. 60:7061–7066. 2004. View Article : Google Scholar
18	Andrews NC and Faller DV: A rapid micropreparation technique for extraction of DNA-binding proteins from limiting numbers of mammalian cells. Nucleic Acids Res. 19:24991991. View Article : Google Scholar : PubMed/NCBI
19	Pétrilli V, Papin S, Dostert C, Mayor A, Martinon F and Tschopp J: Activation of the NALP3 inflammasome is triggered by low intracellular potassium concentration. Cell Death Differ. 14:1583–1589. 2007. View Article : Google Scholar : PubMed/NCBI
20	Hussain S, Vanoirbeek JA, Luyts K, De Vooght V, Verbeken E, Thomassen LC, Martens JA, Dinsdale D, Boland S, Marano F, et al: Lung exposure to nanoparticles modulates an asthmatic response in a mouse model. Eur Respir J. 37:299–309. 2011. View Article : Google Scholar : PubMed/NCBI
21	Bomsztyk K, Rooney WJ, Iwasaki T, Rachie AN, Dower KS and Sibley HC: Evidence that interleukin-1 and phorbol esters activate NF-kappaB by different pathways: Role of protein kinase C. Cell Regul. 2:329–335. 1991. View Article : Google Scholar : PubMed/NCBI
22	Watanabe M, Ohsugi T, Shoda M, Ishida T, Aizawa S, Maruyama-Nagai M, Utsunomiya A, Koga S, Yamada Y, Kamihira S, et al: Dual targeting of transformed and untransformed HTLV-1-infected T-cells by DHMEQ, a potent and selective inhibitor of NF-kappaB, as a strategy for chemoprevention and therapy of adult T cell leukemia. Blood. 106:2462–2471. 2005. View Article : Google Scholar : PubMed/NCBI
23	Horie R, Watanabe M, Okamura T, Taira M, Shoda M, Motoji T, Utsunomiya A, Watanabe T, Higashihara M and Umezawa K: DHMEQ, a new NF-kappaB inhibitor, induces apoptosis and enhances fludarabine effects on chronic lymphocytic leukemia cells. Leukemia. 20:800–806. 2006. View Article : Google Scholar : PubMed/NCBI
24	Morishige T, Yoshioka Y, Tanabe A, Yao X, Tsunoda S, Tsutsumi Y, Mukai Y, Okada N and Nakagawa S: Titanium dioxide induces different levels of IL-1beta production dependent on its particle characteristics through caspase-1 activation mediated by reactive oxygen species and cathepsin B. Biochem Biophys Res Commun. 392:160–165. 2010. View Article : Google Scholar : PubMed/NCBI
25	Youm YH, Nguyen KY, Grant RW, Goldberg EL, Bodogai M, Kim D, D'Agostino D, Planavsky N, Lupfer C, Kanneganti TD, et al: The ketone metabolite β-hydroxybutyrate blocks NLRP3 inflammasome-mediated inflammatory disease. Nat Med. 21:263–269. 2015. View Article : Google Scholar : PubMed/NCBI
26	Fink SL and Cookson BT: Apoptosis, pyroptosis, and necrosis: Mechanistic description of dead and dying eukaryotic cells. Infect Immun. 73:1907–1916. 2005. View Article : Google Scholar : PubMed/NCBI
27	Yazdi AS, Guarda G, Riteau N, Drexler SK, Tardivel A, Couillin I and Tschopp J: Nanoparticles activate the NLR pyrin domain containing 3 (Nlrp3) inflammasome and cause pulmonary inflammation through release of IL-1α and IL-1β. Proc Natl Acad Sci USA. 107:19449–19454. 2010. View Article : Google Scholar : PubMed/NCBI
28	Van de Veerdonk LF, Smeekens PS, Joosten BAL, Kullberg JB, Dinarello AC, van der Meer MWJ and Netea GM: Reactive oxygen species-independent activation of the IL-1β inflammasome in cells from patients with chronic granulomatous disease. Proc Natl Acad Sci USA. 107:3030–3033. 2010. View Article : Google Scholar : PubMed/NCBI
29	Iyer SS, He Q, Janczy JR, Elliott EI, Zhong Z, Olivier AK, Sadler JJ, Knepper-Adrian V, Han R, Qiao L, et al: Mitochondrial cardiolipin is required for Nlrp3 inflammasome activation. Immunity. 39:311–323. 2013. View Article : Google Scholar : PubMed/NCBI
30	Hamasaka A, Yoshioka N, Abe R, Kishino S, Umezawa K, Ozaki M, Todo S and Shimizu H: Topical application of dehydroxymethylepoxyquinomicinimproves allergic inflammation via NF-kappaB inhibition. J Allergy Clin Immunol. 126:400–403. 2010. View Article : Google Scholar : PubMed/NCBI
31	Jiang X, Lan Y, Wei B, Dai C, Gu Y, Ma J, Liu X, Umezawa K and Zhang Y: External application of NF-κB inhibitor DHMEQ suppresses development of atopic dermatitis-like lesions induced with DNCB/OX in BALB/c mice. Immunopharmacol Immunotoxicol. 39:157–164. 2017. View Article : Google Scholar : PubMed/NCBI
32	Shimo T, Adachi Y, Umezawa K, Okigaki M, Takaya J, Taniuchi S, Ikehara S and Kaneko K: Dehydroxymethylepoxyquinomicin (DHMEQ) can suppress tumour necrosis factor-α production in lipopolysaccharide-injected mice, resulting in rescuing mice from death in vivo. Clin Exp Immunol. 166:299–306. 2011. View Article : Google Scholar : PubMed/NCBI
33	Shimizu K, Konno S, Ozaki M, Umezawa K, Yamashita K, Todo S and Nishimura M: Dehydroxymethylepoxyquinomicin (DHMEQ), a novel NF-kappa B inhibitor, inhibits allergic inflammation and airway remodelling in murine models of asthma. Clin Exp Allergy. 42:1273–1281. 2012. View Article : Google Scholar : PubMed/NCBI
