Identification of key genes for predicting colorectal cancer prognosis by integrated bioinformatics analysis

Dai,Gong‑Peng; Wang,Li‑Ping; Wen,Yu‑Qing; Ren,Xue‑Qun; Zuo,Shu‑Guang

doi:10.3892/ol.2019.11068

Identification of key genes for predicting colorectal cancer prognosis by integrated bioinformatics analysis

Authors:
- Gong‑Peng Dai
- Li‑Ping Wang
- Yu‑Qing Wen
- Xue‑Qun Ren
- Shu‑Guang Zuo
View Affiliations

Affiliations: Department of General Surgery, Huaihe Hospital of Henan University, Kaifeng, Henan 475001, P.R. China, Center for Translational Medicine, Huaihe Hospital of Henan University, Kaifeng, Henan 475001, P.R. China
Published online on: November 7, 2019 https://doi.org/10.3892/ol.2019.11068
Pages: 388-398
Copyright: © Dai et al. This is an open access article distributed under the terms of Creative Commons Attribution License.

Metrics: Total Views: 0 (Spandidos Publications: | PMC Statistics: )

Metrics: Total PDF Downloads: 0 (Spandidos Publications: | PMC Statistics: )

Cited By (CrossRef): 0 citations Loading Articles...

Abstract

Colorectal cancer (CRC) is a life‑threatening disease with a poor prognosis. Therefore, it is crucial to identify molecular prognostic biomarkers for CRC. The present study aimed to identify potential key genes that could be used to predict the prognosis of patients with CRC. Three CRC microarray datasets (GSE20916, GSE73360 and GSE44861) were downloaded from the Gene Expression Omnibus (GEO) database, and one dataset was obtained from The Cancer Genome Atlas (TCGA) database. The three GEO datasets were analyzed to detect differentially expressed genes (DEGs) using the BRB‑ArrayTools software. Functional and pathway enrichment analyses of these DEGs were performed using the Database for Annotation, Visualization and Integrated Discovery tool. A protein‑protein interaction (PPI) network of DEGs was constructed, hub genes were extracted, and modules of the PPI network were analyzed. To investigate the prognostic values of the hub genes in CRC, data from the CRC datasets of TCGA were used to perform the survival analyses based on the sample splitting method and Cox regression model. Correlation among the hub genes was evaluated using Spearman's correlation analysis. In the three GEO datasets, a total of 105 common DEGs were identified, including 51 down‑ and 54 up‑regulated genes in CRC compared with normal colorectal tissues. A PPI network consisting of 100 DEGs and 551 edges was constructed, and 44 nodes were identified as hub genes. Among these 44 genes, the four hub genes TIMP metallopeptidase inhibitor 1 (TIMP1), solute carrier family 4 member 4 (SLC4A4), aldo‑keto reductase family 1 member B10 (AKR1B10) and ATP binding cassette subfamily E member 1 (ABCE1) were associated with overall survival (OS) in patients with CRC. Three significant modules were extracted from the PPI network. The hub gene TIMP1 was present in Module 1, ABCE1 was involved in Module 2 and SLC4A4 was identified in Module 3. Univariate analysis revealed that TIMP1, SLC4A4, AKR1B10 and ABCE1 were associated with the OS of patients with CRC. Multivariate analysis demonstrated that SLC4A4 may be an independent prognostic factor associated with OS. Furthermore, the results from correlation analysis revealed that there was no correlation between TIMP1, SLC4A4 and ABCE1, whereas AKR1B10 was positively correlated with SLC4A4. In conclusion, the four key genes TIMP1, SLC4A4, AKR1B10 and ABCE1 associated with the OS of patients with CRC were identified by integrated bioinformatics analysis. These key genes may be used as prognostic biomarkers to predict the survival of patients with CRC, and may therefore represent novel therapeutic targets for CRC.

View Figures

View References

1	Siegel R, Desantis C and Jemal A: Colorectal cancer statistics, 2014. CA Cancer J Clin. 64:104–117. 2014. View Article : Google Scholar : PubMed/NCBI
2	Bray F, Ferlay J, Soerjomataram I, Siegel RL, Torre LA and Jemal A: Global cancer statistics 2018: GLOBOCAN estimates of incidence and mortality worldwide for 36 cancers in 185 countries. CA Cancer J Clin. 68:394–424. 2018. View Article : Google Scholar : PubMed/NCBI
3	Leslie A and Steele RJ: Management of colorectal cancer. Postgrad Med J. 78:473–478. 2002. View Article : Google Scholar : PubMed/NCBI
4	Renkonen-Sinisalo L, Aarnio M, Mecklin JP and Järvinen HJ: Surveillance improves survival of colorectal cancer in patients with hereditary nonpolyposis colorectal cancer. Cancer Detect Prev. 24:137–142. 2000.PubMed/NCBI
5	Siegel RL, Miller KD, Fedewa SA, Ahnen DJ, Meester RGS, Barzi A and Jemal A: Colorectal cancer statistics, 2017. CA Cancer J Clin. 67:177–193. 2017. View Article : Google Scholar : PubMed/NCBI
6	Chen W, Zheng R, Zeng H, Zhang S and He J: Annual report on status of cancer in China, 2011. Chin J Cancer Res. 27:2–12. 2015. View Article : Google Scholar : PubMed/NCBI
7	Derry MM, Raina K, Agarwal C and Agarwal R: Identifying molecular targets of lifestyle modifications in colon cancer prevention. Front Oncol. 3:1192013. View Article : Google Scholar : PubMed/NCBI
8	Sakai E, Fukuyo M, Ohata K, Matsusaka K, Doi N, Mano Y, Takane K, Abe H, Yagi K, Matsuhashi N, et al: Genetic and epigenetic aberrations occurring in colorectal tumors associated with serrated pathway. Int J Cancer. 138:1634–1644. 2016. View Article : Google Scholar : PubMed/NCBI
9	Mlcochova J, Faltejskova P, Nemecek R, Svoboda M and Slaby O: MicroRNAs targeting EGFR signalling pathway in colorectal cancer. J Cancer Res Clin Oncol. 139:1615–1624. 2013. View Article : Google Scholar : PubMed/NCBI
10	Takahashi T, Shigematsu H, Shivapurkar N, Reddy J, Zheng Y, Feng Z, Suzuk M, Nomura M, Augustus M, Yin J, et al: Aberrant promoter methylation of multiple genes during multistep pathogenesis of colorectal cancers. Int J Cancer. 118:924–931. 2006. View Article : Google Scholar : PubMed/NCBI
11	Schirripa M and Lenz HJ: Biomarker in Colorectal Cancer. Cancer J. 22:156–164. 2016. View Article : Google Scholar : PubMed/NCBI
12	Bustin SA and Dorudi S: Gene expression profiling for molecular staging and prognosis prediction in colorectal cancer. Expert Rev Mol Diagn. 4:599–607. 2004. View Article : Google Scholar : PubMed/NCBI
13	Kulasingam V and Diamandis EP: Strategies for discovering novel cancer biomarkers through utilization of emerging technologies. Nat Clin Pract Oncol. 5:588–599. 2008. View Article : Google Scholar : PubMed/NCBI
14	Nannini M, Pantaleo MA, Maleddu A, Astolfi A, Formica S and Biasco G: Gene expression profiling in colorectal cancer using microarray technologies: Results and perspectives. Cancer Treat Rev. 35:201–209. 2009. View Article : Google Scholar : PubMed/NCBI
15	Liang B, Li C and Zhao J: Identification of key pathways and genes in colorectal cancer using bioinformatics analysis. Med Oncol. 33:1112016. View Article : Google Scholar : PubMed/NCBI
16	Skrzypczak M, Goryca K, Rubel T, Paziewska A, Mikula M, Jarosz D, Pachlewski J, Oledzki J and Ostrowski J: Modeling oncogenic signaling in colon tumors by multidirectional analyses of microarray data directed for maximization of analytical reliability. PLoS One. 5:e130912010. View Article : Google Scholar : PubMed/NCBI
17	Condorelli DF, Spampinato G, Valenti G, Musso N, Castorina S and Barresi V: Positive caricature transcriptomic effects associated with broad genomic aberrations in colorectal cancer. Sci Rep. 8:148262018. View Article : Google Scholar : PubMed/NCBI
18	Ryan BM, Zanetti KA, Robles AI, Schetter AJ, Goodman J, Hayes RB, Huang WY, Gunter MJ, Yeager M, Burdette L, et al: Germline variation in NCF4, an innate immunity gene, is associated with an increased risk of colorectal cancer. Int J Cancer. 134:1399–1407. 2014. View Article : Google Scholar : PubMed/NCBI
19	Rich JN, Hans C, Jones B, Iversen ES, McLendon RE, Rasheed BK, Dobra A, Dressman HK, Bigner DD, Nevins JR and West M: Gene expression profiling and genetic markers in glioblastoma survival. Cancer Res. 65:4051–4058. 2005. View Article : Google Scholar : PubMed/NCBI
20	Simon R, Lam A, Li MC, Ngan M, Menenzes S and Zhao Y: Analysis of gene expression data using BRB-array tools. Cancer Inform. 3:11–17. 2007. View Article : Google Scholar : PubMed/NCBI
21	von Mering C, Huynen M, Jaeggi D, Schmidt S, Bork P and Snel B: STRING: A database of predicted functional associations between proteins. Nucleic Acids Res. 31:258–261. 2003. View Article : Google Scholar : PubMed/NCBI
22	Smoot ME, Ono K, Ruscheinski J, Wang PL and Ideker T: Cytoscape 2.8: New features for data integration and network visualization. Bioinformatics. 27:431–432. 2011. View Article : Google Scholar : PubMed/NCBI
23	Otte E and Rousseau R: Social network analysis: A powerful strategy, also for the information sciences. J Inform Sci. 28:441–453. 2002. View Article : Google Scholar
24	Rhrissorrakrai K and Gunsalus KC: MINE: Module identification in networks. BMC Bioinformatics. 12:1922011. View Article : Google Scholar : PubMed/NCBI
25	Ashburner M, Ball CA, Blake JA, Botstein D, Butler H, Cherry JM, Davis AP, Dolinski K, Dwight SS, Eppig JT, et al: Gene ontology: Tool for the unification of biology. The Gene Ontology Consortium. Nat Genet. 25:25–29. 2000. View Article : Google Scholar : PubMed/NCBI
26	Ogata H, Goto S, Sato K, Fujibuchi W, Bono H and Kanehisa M: KEGG: Kyoto Encyclopedia of Genes and Genomes. Nucleic Acids Res. 27:29–34. 1999. View Article : Google Scholar : PubMed/NCBI
27	Huang da W, Sherman BT and Lempicki RA: Systematic and integrative analysis of large gene lists using DAVID bioinformatics resources. Nat Protoc. 4:44–57. 2009. View Article : Google Scholar : PubMed/NCBI
28	Merico D, Isserlin R, Stueker O, Emili A and Bader GD: Enrichment map: A network-based method for gene-set enrichment visualization and interpretation. PLoS One. 5:e139842010. View Article : Google Scholar : PubMed/NCBI
29	Huang SH, Xu W, Waldron J, Siu L, Shen X, Tong L, Ringash J, Bayley A, Kim J, Hope A, et al: Refining American Joint Committee on Cancer/Union for International Cancer Control TNM stage and prognostic groups for human papillomavirus-related oropharyngeal carcinomas. J Clin Oncol. 33:836–845. 2015. View Article : Google Scholar : PubMed/NCBI
30	Ramaswamyreddy SH and Smitha T: Microarray-based gene expression profiling for early detection of oral squamous cell carcinoma. J Oral Maxillofac Pathol. 22:293–295. 2018.PubMed/NCBI
31	Salem H, Attiya G and El-Fishawy N: Classification of human cancer diseases by gene expression profiles. Appl Soft Comput. 50:124–134. 2017. View Article : Google Scholar
32	Li G, Li X, Yang M, Xu L, Deng S and Ran L: Prediction of biomarkers of oral squamous cell carcinoma using microarray technology. Sci Rep. 7:421052017. View Article : Google Scholar : PubMed/NCBI
33	Romero MF, Hediger MA, Boulpaep EL and Boron WF: Expression cloning and characterization of a renal electrogenic Na+/HCO3-cotransporter. Nature. 387:409–413. 1997. View Article : Google Scholar : PubMed/NCBI
34	Romero MF, Fulton CM and Boron WF: The SLC4 family of HCO 3-transporters. Pflugers Arch. 447:495–509. 2004. View Article : Google Scholar : PubMed/NCBI
35	Gomez-Rueda H, Palacios-Corona R, Gutiérrez-Hermosillo H and Trevino V: A robust biomarker of differential correlations improves the diagnosis of cytologically indeterminate thyroid cancers. Int J Mol Med. 37:1355–1362. 2016. View Article : Google Scholar : PubMed/NCBI
36	Chen S, Zhang L, Su Y and Zhang X: Screening potential biomarkers for colorectal cancer based on circular RNA chips. Oncol Rep. 39:2499–2512. 2018.PubMed/NCBI
37	Zhao ZW, Fan XX, Yang LL, Song JJ, Fang SJ, Tu JF, Chen MJ, Zheng LY, Wu FZ, Zhang DK, et al: The identification of a common different gene expression signature in patients with colorectal cancer. Math Biosci Eng. 16:2942–2958. 2019.PubMed/NCBI
38	Bisbal C, Martinand C, Silhol M, Lebleu B and Salehzada T: Cloning and Characterization of a RNase L Inhibitor A new component of the interferon-regulated 2-5A pathway. J Biol Chem. 270:13308–13317. 1995. View Article : Google Scholar : PubMed/NCBI
39	Pestka S, Langer JA, Zoon KC and Samuel CE: Interferons and their actions. Annu Rev Biochem. 56:727–777. 1987. View Article : Google Scholar : PubMed/NCBI
40	Zheng D, Dai Y, Wang S and Xing X: MicroRNA-299-3p promotes the sensibility of lung cancer to doxorubicin through directly targeting ABCE1. Int J Clin Exp Pathol. 8:10072–10081. 2015.PubMed/NCBI
41	Hlavata I, Mohelnikova-Duchonova B, Vaclavikova R, Liska V, Pitule P, Novak P, Bruha J, Vycital O, Holubec L, Treska V, et al: The role of ABC transporters in progression and clinical outcome of colorectal cancer. Mutagenesis. 27:187–196. 2012. View Article : Google Scholar : PubMed/NCBI
42	Huang B, Zhou H, Lang X and Liu Z: siRNA-induced ABCE1 silencing inhibits proliferation and invasion of breast cancer cells. Mol Med Rep. 10:1685–1690. 2014. View Article : Google Scholar : PubMed/NCBI
43	Huang B, Gao Y, Tian D and Zheng M: A small interfering ABCE1-targeting RNA inhibits the proliferation and invasiveness of small cell lung cancer. Int J Mol Med. 25:687–693. 2010.PubMed/NCBI
44	Shichijo S, Ishihara Y, Azuma K, Komatsu N, Higashimoto N, Ito M, Nakamura T, Ueno T, Harada M and Itoh K: ABCE1, a member of ATP-binding cassette transporter gene, encodes peptides capable of inducing HLA-A2-restricted and tumor-reactive cytotoxic T lymphocytes in colon cancer patients. Oncol Rep. 13:907–913. 2005.PubMed/NCBI
45	Wang YY, Li L, Zhao ZS and Wang HJ: Clinical utility of measuring expression levels of KAP1, TIMP1 and STC2 in peripheral blood of patients with gastric cancer. World J Surg Oncol. 11:812013. View Article : Google Scholar : PubMed/NCBI
46	Bjerre C, Vinther L, Belling KC, Würtz SØ, Yadav R, Lademann U, Rigina O, Do KN, Ditzel HJ, Lykkesfeldt AE, et al: TIMP1 overexpression mediates resistance of MCF-7 human breast cancer cells to fulvestrant and down-regulates progesterone receptor expression. Tumour Biol. 34:3839–3851. 2013. View Article : Google Scholar : PubMed/NCBI
47	Peng L, Yanjiao M, Ai-Guo W, Pengtao G, Jianhua L, Ju Y, Hongsheng O and Xichen Z: A fine balance between CCNL1 and TIMP1 contributes to the development of breast cancer cells. Biochem Biophys Res Commun. 409:344–349. 2011. View Article : Google Scholar : PubMed/NCBI
48	Xiong Y, You W, Wang R, Peng L and Fu Z: Prediction and validation of Hub Genes associated with colorectal cancer by integrating PPI network and gene expression data. Biomed Res Int. 2017:24214592017. View Article : Google Scholar : PubMed/NCBI
49	Song G, Xu S, Zhang H, Wang Y, Xiao C, Jiang T, Wu L, Zhang T, Sun X, Zhong L, et al: TIMP1 is a prognostic marker for the progression and metastasis of colon cancer through FAK-PI3K/AKT and MAPK pathway. J Exp Clin Cancer Res. 35:1482016. View Article : Google Scholar : PubMed/NCBI
50	Kostourou V, Lechertier T, Reynolds LE, Lees DM, Baker M, Jones DT, Tavora B, Ramjaun AR, Birdsey GM, Robinson SD, et al: FAK-heterozygous mice display enhanced tumour angiogenesis. Nat Commun. 4:20202013. View Article : Google Scholar : PubMed/NCBI
51	Oudart JB, Doué M, Vautrin A, Brassart B, Sellier C, Dupont-Deshorgue A, Monboisse JC, Maquart FX, Brassart-Pasco S and Ramont L: The anti-tumor NC1 domain of collagen XIX inhibits the FAK/PI3K/Akt/mTOR signaling pathway through αvβ3 integrin interaction. Oncotarget. 7:1516–1528. 2016. View Article : Google Scholar : PubMed/NCBI
52	Kapur R, Cooper R, Zhang L and Williams DA: Cross-talk between alpha(4)beta(1)/alpha(5)beta(1) and c-Kit results in opposing effect on growth and survival of hematopoietic cells via the activation of focal adhesion kinase, mitogen-activated protein kinase, and Akt signaling pathways. Blood. 97:1975–1981. 2001. View Article : Google Scholar : PubMed/NCBI
53	Ko HH, Cheng SL, Lee JJ, Chen HM, Kuo MY and Cheng SJ: Expression of AKR1B10 as an independent marker for poor prognosis in human oral squamous cell carcinoma. Head Neck. 39:1327–1332. 2017. View Article : Google Scholar : PubMed/NCBI
54	Sinreih M, Štupar S, Čemažar L, Verdenik I, Frković Grazio S, Smrkolj Š and Rižner TL: STAR and AKR1B10 are down-regulated in high-grade endometrial cancer. J Steroid Biochem Mol Bio. 171:43–53. 2017. View Article : Google Scholar
55	Huang B, Gong X, Zhou H, Xiong F and Wang S: Depleting ABCE1 expression induces apoptosis and inhibits the ability of proliferation and migration of human esophageal carcinoma cells. Int J Clin Exp Pathol. 7:584–592. 2014.PubMed/NCBI
56	Li Q, Shen F and Wang C: TUC338 promotes cell migration and invasion by targeting TIMP1 in cervical cancer. Oncol Lett. 13:4526–4532. 2017. View Article : Google Scholar : PubMed/NCBI
57	Petitjean A, Mathe E, Kato S, Ishioka C, Tavtigian SV, Hainaut P and Olivier M: Impact of mutant p53 functional properties on TP53 mutation patterns and tumor phenotype: Lessons from recent developments in the IARC TP53 database. Hum Mutat. 28:622–629. 2007. View Article : Google Scholar : PubMed/NCBI
58	Taskoparan B, Seza EG, Demirkol S, Tuncer S, Stefek M, Gure AO and Banerjee S: Opposing roles of the aldo-keto reductases AKR1B1 and AKR1B10 in colorectal cancer. Cell Oncol (Dordr). 40:563–578. 2017. View Article : Google Scholar : PubMed/NCBI
