Isolation of circulating tumor cells and detection of EGFR mutations in patients with non‑small‑cell lung cancer

Zhang,Qi; Nong,Jingying; Wang,Jinghui; Yan,Zhuohong; Yi,Ling; Gao,Xin; Liu,Zhidong; Zhang,Hongtao; Zhang,Shucai

doi:10.3892/ol.2019.10016

Isolation of circulating tumor cells and detection of EGFR mutations in patients with non‑small‑cell lung cancer

Authors:
- Qi Zhang
- Jingying Nong
- Jinghui Wang
- Zhuohong Yan
- Ling Yi
- Xin Gao
- Zhidong Liu
- Hongtao Zhang
- Shucai Zhang
View Affiliations

Affiliations: Department of Oncology, Beijing Chest Hospital, Capital Medical University, Beijing Tuberculosis and Thoracic Tumor Research Institute, Beijing 101149, P.R. China, Department of Central Laboratory, Beijing Chest Hospital, Capital Medical University, Beijing Tuberculosis and Thoracic Tumor Research Institute, Beijing 101149, P.R. China, Department of Thoracic Surgery, Beijing Chest Hospital, Capital Medical University, Beijing Tuberculosis and Thoracic Tumor Research Institute, Beijing 101149, P.R. China
Published online on: February 5, 2019 https://doi.org/10.3892/ol.2019.10016
Pages: 3799-3807
Copyright: © Zhang et al. This is an open access article distributed under the terms of Creative Commons Attribution License.

Metrics: Total Views: 0 (Spandidos Publications: | PMC Statistics: )

Metrics: Total PDF Downloads: 0 (Spandidos Publications: | PMC Statistics: )

Cited By (CrossRef): 0 citations Loading Articles...

Abstract

The aim of the present study was to develop a procedure for the isolation of circulating tumor cells (CTCs), and to evaluate its application in the detection of epidermal growth factor receptor (EGFR) mutations, and potential heterogeneity in patients with non‑small‑cell lung cancer (NSCLC). Peripheral blood samples were collected from 91 patients with lung cancer, 10 patients with benign disease and 10 healthy volunteers. CTCs were enriched by positive immunomagnetic separation, detected by immunocytochemistry, and processed for single‑cell capture. Pure CTC DNA was amplified, and the EGFR gene was analyzed using the amplification refractory mutation system (ARMS) and digital polymerase chain reaction (dPCR). The CTC capture rate in patients with lung cancer was 61.5% (56/91), whereas no CTCs were detected in patients with benign lung disease or in healthy volunteers. The CTC‑positive detection rates were 69.3% (52/75) and 25.0% (4/16) in patients with TNM stage III and IV disease, respectively. Markedly more CTCs were captured from patients with small‑cell lung cancer compared with patients with other types of cancer. In patients who were positive for EGFR mutations, the detection rate of these mutations was low (16.67%, 2/12), at the single CTC level. The sensitivity increased as the number of CTCs per sample increased. A total of four patients displayed consistent detection of EGFR mutations at the 10‑cell level, and one patient exhibited a clear, inconsistent and rare mutation (G719x) between CTCs. A simplified technique for isolating CTCs from blood was established, though multiple CTCs were required to sensitively detect mutations in these cells. The detection of EGFR mutations in CTCs and tissue specimens was generally homogeneous, and therefore, the CTC‑level mutation analysis may potentially contribute to the discovery of heterogeneous mutations.

View Figures

View References

1	Siegel RL, Miller KD and Jemal A: Cancer statistics, 2017. CA Cancer J Clin. 67:7–30. 2017. View Article : Google Scholar : PubMed/NCBI
2	Carmichael J, Wing-san Mak D and O Brien M: A review of recent advances in the treatment of elderly and poor performance NSCLC. Cancers (Basel). 10(E236)2018.PubMed/NCBI
3	Nagano T, Tachihara M and Nishimura Y: Mechanism of resistance to epidermal growth factor receptor-tyrosine kinase inhibitors and a potential treatment strategy. Cells. 7(E212)2018.PubMed/NCBI
4	Cooper MR, Alrajhi AM and Durand CR: Role of immune checkpoint inhibitors in small cell lung cancer. Am J Ther. 25:e349–e356. 2018. View Article : Google Scholar : PubMed/NCBI
5	Rosell R, Moran T, Queralt C, Porta R, Cardenal F, Camps C, Majem M, Lopez-Vivanco G, Isla D, Provencio M, et al: Screening for epidermal growth factor receptor mutations in lung cancer. N Engl J Med. 361:958–967. 2009. View Article : Google Scholar : PubMed/NCBI
6	Wu YL, Zhong WZ, Li LY, Zhang XT, Zhang L, Zhou CC, Liu W, Jiang B, Mu XL, Lin JY, et al: Epidermal growth factor receptor mutations and their correlation with gefitinib therapy in patients with non-small cell lung cancer: A meta-analysis based on updated individual patient data from six medical centers in mainland China. J Thorac Oncol. 2:430–439. 2007. View Article : Google Scholar : PubMed/NCBI
7	Maheswaran S, Sequist LV, Nagrath S, Ulkus L, Brannigan B, Collura CV, Inserra E, Diederichs S, Iafrate AJ, Bell DW, et al: Detection of mutations in EGFR in circulating lung-cancer cells. N Engl J Med. 359:366–377. 2008. View Article : Google Scholar : PubMed/NCBI
8	Allard WJ, Matera J, Miller MC, Repollet M, Connelly MC, Rao C, Tibbe AG, Uhr JW and Terstappen LW: Tumor cells circulate in the peripheral blood of all major carcinomas but not in healthy subjects or patients with nonmalignant diseases. Clin Cancer Res. 10:6897–6904. 2004. View Article : Google Scholar : PubMed/NCBI
9	Hou J, Greystoke A, Lancashire L, Cummings J, Ward T, Board R, Amir E, Hughes S, Krebs M, Hughes A, et al: Evaluation of circulating tumor cells and serological cell death biomarkers in small cell lung cancer patients undergoing chemotherapy. Am J Pathol. 175:808–816. 2009. View Article : Google Scholar : PubMed/NCBI
10	Li H and Durbin R: Fast and accurate short read alignment with burrows-wheeler transform. Bioinformatics. 25:1754–1760. 2009. View Article : Google Scholar : PubMed/NCBI
11	Li H and Durbin R: Fast and accurate long-read alignment with burrows-wheeler transform. Bioinformatics. 26:589–595. 2010. View Article : Google Scholar : PubMed/NCBI
12	Parkinson DR, Dracopoli N, Petty BG, Compton C, Cristofanilli M, Deisseroth A, Hayes DF, Kapke G, Kumar P, Lee JSH, et al: Considerations in the development of circulating tumor cell technology for clinical use. J Transl Med. 10:1382012. View Article : Google Scholar : PubMed/NCBI
13	Alix-Panabières C and Pantel K: Challenges in circulating tumour cell research. Nat Rev Cancer. 14:623–631. 2014. View Article : Google Scholar : PubMed/NCBI
14	Went PT, Lugli A, Meier S, Bundi M, Mirlacher M, Sauter G and Dirnhofer S: Frequent EpCam protein expression in human carcinomas. Hum Pathol. 35:122–128. 2004. View Article : Google Scholar : PubMed/NCBI
15	Broers JL, Ramaekers FC, Rot MK, Oostendorp T, Huysmans A, van Muijen GN, Wagenaar SS and Vooijs GP: Cytokeratins in different types of human lung cancer as monitored by chain-specific monoclonal antibodies. Cancer Res. 48:3221–3229. 1988.PubMed/NCBI
16	O Flaherty JD, Gray S, Richard D, Fennell D, O Leary JJ, Blackhall FH and O Byrne KJ: Circulating tumour cells, their role in metastasis and their clinical utility in lung cancer. Lung Cancer. 76:19–25. 2012. View Article : Google Scholar : PubMed/NCBI
17	Punnoose EA, Atwal SK, Spoerke JM, Savage H, Pandita A, Yeh RF, Pirzkall A, Fine BM, Amler LC, Chen DS and Lackner MR: Molecular biomarker analyses using circulating tumor cells. PLoS One. 5:e125172010. View Article : Google Scholar : PubMed/NCBI
18	Krebs MG, Sloane R, Priest L, Lancashire L, Hou JM, Greystoke A, Ward TH, Ferraldeschi R, Hughes A, Clack G, et al: Evaluation and prognostic significance of circulating tumor cells in patients with non-small-cell lung cancer. J Clin Oncol. 29:1556–1563. 2011. View Article : Google Scholar : PubMed/NCBI
19	Tanaka F, Yoneda K, Kondo N, Hashimoto M, Takuwa T, Matsumoto S, Okumura Y, Rahman S, Tsubota N, Tsujimura T, et al: Circulating tumor cell as a diagnostic marker in primary lung cancer. Clin Cancer Res. 15:6980–6986. 2009. View Article : Google Scholar : PubMed/NCBI
20	Hou J, Krebs MG, Lancashire L, Sloane R, Backen A, Swain RK, Priest LJ, Greystoke A, Zhou C, Morris K, et al: Clinical significance and molecular characteristics of circulating tumor cells and circulating tumor microemboli in patients with small-cell lung cancer. J Clin Oncol. 30:525–532. 2012. View Article : Google Scholar : PubMed/NCBI
21	Thress KS, Brant R, Carr TH, Dearden S, Jenkins S, Brown H, Hammett T, Cantarini M and Barrett JC: EGFR mutation detection in ctDNA from NSCLC patient plasma: A cross-platform comparison of leading technologies to support the clinical development of AZD9291. Lung Cancer. 90:509–515. 2015. View Article : Google Scholar : PubMed/NCBI
22	Bordi P, Del Re M, Danesi R and Tiseo M: Circulating DNA in diagnosis and monitoring EGFR gene mutations in advanced non-small cell lung cancer. Transl Lung Cancer Res. 4:584–597. 2015.PubMed/NCBI
23	Qiu M, Wang J, Xu Y, Ding X, Li M, Jiang F, Xu L and Yin R: Circulating tumor DNA is effective for the detection of EGFR mutation in non-small cell lung cancer: A meta-analysis. Cancer Epidemiol Biomarkers Prev. 24:206–212. 2015. View Article : Google Scholar : PubMed/NCBI
24	Jahr S, Hentze H, Englisch S, Hardt D, Fackelmayer FO, Hesch RD and Knippers R: DNA fragments in the blood plasma of cancer patients: Quantitations and evidence for their origin from apoptotic and necrotic cells. Cancer Res. 61:1659–1665. 2001.PubMed/NCBI
25	Alix-Panabières C and Pantel K: Circulating tumor cells: Liquid biopsy of cancer. Clin Chem. 59:110–118. 2013. View Article : Google Scholar : PubMed/NCBI
26	Siravegna G, Marsoni S, Siena S and Bardelli A: Integrating liquid biopsies into the management of cancer. Nat Rev Clin Oncol. 14:531–548. 2017. View Article : Google Scholar : PubMed/NCBI
27	Effenberger KE, Schroeder C, Eulenburg C, Reeh M, Tachezy M, Riethdorf S, Vashist YK, Izbicki JR, Pantel K and Bockhorn M: Disseminated tumor cells in pancreatic cancer-an independent prognosticator of disease progression and survival. Int J Cancer. 131:E475–E483. 2012. View Article : Google Scholar : PubMed/NCBI
28	Nagrath S, Sequist LV, Maheswaran S, Bell DW, Irimia D, Ulkus L, Smith MR, Kwak EL, Digumarthy S, Muzikansky A, et al: Isolation of rare circulating tumour cells in cancer patients by microchip technology. Nature. 450:1235–1239. 2007. View Article : Google Scholar : PubMed/NCBI
29	Gorges TM, Penkalla N, Schalk T, Joosse SA, Riethdorf S, Tucholski J, Lücke K, Wikman H, Jackson S, Brychta N, et al: Enumeration and molecular characterization of tumor cells in lung cancer patients using a novel in vivo device for capturing circulating tumor cells. Clin Cancer Res. 22:2197–2206. 2016. View Article : Google Scholar : PubMed/NCBI
30	Marchetti A, Del Grammastro M, Felicioni L, Malatesta S, Filice G, Centi I, De Pas T, Santoro A, Chella A, Brandes AA, et al: Assessment of EGFR mutations in circulating tumor cell preparations from NSCLC patients by next generation sequencing: Toward a real-time liquid biopsy for treatment. PLoS One. 9:e1038832014. View Article : Google Scholar : PubMed/NCBI
